• Machine Type: Compacta C618
• Paper Flow direction: Right-to-left
• Paper Fiber direction: Long Grain
• Cylinder Circumference: 1,260 mm / 49.6"
• Cutoff: 630 mm / 24.8"
• Paper Width max.: 1,450 mm / 57.1"
• Paper Width min.: 840 mm / 33.1"
• Speed: 42,500 Cylinder rotations / h
• 4 colors
• Control Systems: KBA Opera, DriveTronic, ErgoTronic, ColorTronic, LogoTronic, EasyTronic (EasyGo/EasyStop), QuadTech ICON Central Computer

• Product Height (fixed): 315 mm / 12.4"
• See attachment for a list of possible signatures

Reel Splicer

• Type: KBA Pastomat RC with Patras A

Paper feeding device

• Type: KBA
• Starting point: Reel Splicer
• End point: to superstructure before folding unit

Infeed Unit

• Type: KBA Webtronic

Printing System

• 4 double printing units
• Upright design
• Plate changer: KBA semi-automatic
• Rubber blanket washing system: Oxy-Dry ProTech HS
• Ink Supply: Betz Automatic Ink Supply System
• Dampening solution supply: Technotrans delta.d 300W
• Web catching device: Baldwin WebCatcher S18

Dryer

• Type: Megtec Dual Dry TNV 153-1450 (with ER 70/90-90/6000)
• Cooling unit: KBA KWS/CEII-1450-2A4S-3
• with adjustable rehumidification
• with adjustable silicone application

Folding System

Superstructure

• Color register control: QuadTech MultiCam RGS
• Color density measurement and control system: QuadTech Color Control System
• Max. number of webs: 3
• Turner bar assembly
• Webs Register Control: QuadTech Multicam 30 RCS

Folding Unit

• Type: P5 G-1260
• Cross perforation device
• Longitudinal perforation or slot device
• Paper guiding with puncture needles

Funnel fold

• Max. working width: 1,000 mm / 39.4"
• Max. number of webs: 3

Inline Finishing

• Longitudinal gluing and folding aid device: Planatol 8 MOD-DMP (4x Single AKS-100 + 1x Double AKS-100)

Knife roller cylinder

• Number of cutting knives per circumference : 2

Folding knife cylinder

• Number of folding knives : 5

1st cross fold / Folding jaw cylinder

• Number of folding jaws : 5

2nd vertical fold / chopper

• Number of choppers : 2
• Paddle wheel units: 2

Delivery

• Type: KBA delivery DIN A3

• Mechanical Speed: 42,500 rev./h
